Product Specifications
| Specifications | Fabric Sensor |
|---|---|
| Size | 360x540mm (cushion) 1300x600mm (mattress) (customizable) |
| Thickness | <2.0 mm |
| Pitch | Customizable (minimum 3 mm) |
| Pressure Response Time | 10 ms |
| Sampling Rate | 20 Hz (customizable) |
| Range | 200 kPa (customizable) |
| Operating Voltage | 3.3V |
| Operating Current | 10 mA |
| Communication Interface | USB |
