Product Specifications
| Technical Specifications | Tactile Module |
|---|---|
| Structure | 51 x 15 mm (customizable) 55.55 x 51 mm (customizable) |
| Number of arrays | 6x8（可定制） |
| Measurement Range | 0N–20N |
| Minimum activation force | ≤0.1 N |
| Lifespan | 1 million times |
| Operating Temperature | -20°C to 60°C |
| Operating Humidity | 30–70%RH |
| Sensing Area | Customization Available |
| Force Accuracy | 5–151 TP3 TFS |
| Linearity | ≥95% |
| Sensor Spacing | As low as 0.2 mm |
| Communication Frequency | 100 Hz |
| Communication Protocol | UART/IIC/485 |
